Drafting Services Breakdown

Transparent Pricing

We pride ourselves on competitive and straightforward pricing, calculated as a percentage of your project's value:

• Projects up to $50,000 – we charge 3%, On averaging you pay around $800 - $1,400.

• Projects between $100K and $500K – we charge 2.8%, on averaging you pay around $4K - $6K.

• Projects exceeding $1 million – we charge 2.5%, on averaging you pay around averaging $10K and UP!

For 3D detailing services specific to mechanical rooms or steam systems, an additional fee of $1,000 to $2,000 applies.

What We Need From You

To get started and ensure a smooth drafting process, we’ll need the following materials from your end:

1. Mechanical PDFs: Complete sets of mechanical drawings provided by the architect and engineer for the project.

2. CAD Files: CAD files from Sheet Metal for HVAC designs and as well as if possible but not necessary other trades, such as sprinkler systems.

3. HVAC Equipment and material Details: PDF cut sheets or specifications for all HVAC equipment and material.

Providing these documents upfront will help not lose time so we can deliver accurate, detailed, and field-ready drawings efficiently.

What’s Included

When you choose SARIC DRAFTSMAN SHOP, the price you pay covers the entire drafting process from start to finish. We work quickly and efficiently and we guarantee to deliver high-quality results. There are no hidden fees or additional charges. Our team is committed 24/7 to completing your project and ensuring all drawings are approved by the architect and mechanical engineering team.

As-Built (ASB) drawings are include as part of the package.

Please note:

• On-site surveys are not included in our services.

• We prefer email communication to maintain accurate records, provide easy reference, and save time for both parties.
